Network Optimization Practice: Teams Video Conference Stuck Goodbye??? Solution//Global IPLC service

Network Optimization Practice: Teams Video Conference Stuck Goodbye??? Solution//Global IPLC service provider of Shigeng Communication

一、In today's world where remote and hybrid work has become the norm, Microsoft Teams has become the core tool for communication and collaboration in enterprises. However, many users often encounter problems such as screen lag, audio interruption, high latency, and even connection interruption when using Teams for video conferencing, which seriously affects meeting efficiency and experience. This article will start from reality and combine network principles and optimization methods to provide a practical solution for Teams video conferencing network optimization, helping you completely bid farewell to lag.

1. Root cause analysis of stuttering

To solve a problem, the first step is to identify the source of the problem. Teams lag is usually caused by the following reasons:

1. Insufficient local network bandwidth

The upstream/downstream bandwidth is insufficient to support high-definition video streaming (recommended at least 1.5 Mbps upstream).

Multiple devices share the same network and compete for bandwidth resources.

2. High network latency and jitter

International links or cross operator access result in high latency (>150ms).

Network jitter is significant, causing audio and video packets to be out of order or lost.

3. Improper firewall/NAT configuration

The enterprise firewall did not release the required port or domain name for Teams.

Excessive restrictions on UDP traffic have forced Teams to revert back to inefficient TCP mode.

4. The distance between the server access point (Media Processor) is far

If Teams' media relay nodes (such as Azure Media Relay) are deployed overseas, domestic users will face high latency when connecting directly.

5. Terminal device performance bottleneck

Excessive CPU usage, incompatible camera drivers, and outdated operating systems can indirectly cause the illusion of "network lag".

2. Optimization Strategy and Practical Steps

✅  Step 1: Confirm the basic network conditions

Speed verification

Downward speed ≥ 2 Mbps

Upstream speed ≥ 1.5 Mbps (720p video)

Delay<100ms (ideal),<150ms is acceptable

Shake<30ms

Use Microsoft Teams network testing tool or Speedtest to test:

Check Teams media diagnostics

Click on "..." in the upper right corner of the Teams meeting ->"Display Device Settings" ->"View Call Quality"

Attention: packet loss rate (should be<1%), latency, codec status

✅  Step 2: Optimize the local network environment

Wired priority: Try to use Ethernet cables instead of Wi Fi to avoid wireless interference.

QoS settings (applicable to enterprise routers/switches):

Set high priority for Teams traffic (UDP 3478-3481, 50000-59999).

Enable DSCP tagging (such as EF for audio, AF41 for video).

Limit backend usage: disable high bandwidth applications such as cloud synchronization, video downloads, and P2P software.

✅  Step 3: Configure enterprise network strategy (IT administrator perspective)

Microsoft Teams relies heavily on a large number of Microsoft cloud service endpoints. Enterprises must ensure smooth flow of the following:

1. Required domain name and IP address for release

Refer to the official document: Office 365 URLs and IP address ranges

The key domain names include:

*.teams.microsoft.com

*.skype.com

*.microsoft.com

*.azure.com

*.cloudapp.net

⚠️  Do not only release IP addresses, as Microsoft Cloud IP dynamically changes frequently and should be primarily based on FQDN.

2. Enable UDP priority

Teams prioritizes using UDP for real-time audio and video transmission (low latency) by default.

If the firewall blocks UDP, it will automatically downgrade to TCP, resulting in lag.

Suggested strategy: Allow outbound UDP to the aforementioned domain/IP, especially ports 3478-3481 (STUN/TURN) and 50000-59999 (media streams).

3. Deploy local media bypass

For enterprises with Skype for Business Server or Direct Routing, media bypass can be configured to allow audio and video traffic to communicate directly point-to-point without passing through SBC, significantly reducing latency.

✅  Step 4: Utilize Microsoft Global Accelerator Services (for multinational corporations)

If the team is distributed globally, especially for Chinese users accessing overseas Teams services:

Enable Azure Front Door or Azure Virtual WAN

Intelligently schedule Teams traffic through Microsoft's global backbone network to avoid public network congestion.

Consider deploying localized access points

Microsoft has already operated Office 365 (including Teams) in China through Century Internet. Domestic users should use the Century Internet version (login. partner. Microsoft. online. cn) instead of the international version (login. Microsoft. online. com), which can significantly improve performance.

📌  Tip: There is no compliant data center in Chinese Mainland for the international version of Teams. Most media relay nodes are located in Singapore or Hong Kong, and the delay is generally>200ms.

✅  Step 5: Terminal side optimization

Update the Teams client to the latest version.

Turn off 'Automatically adjust video quality' in Teams settings (for stable image quality).

Use an external USB camera and headphones to reduce the resource pressure on the device.

Turn on the "Excellent Performance" power mode on the Windows system (Control Panel → Power Options).

Conclusion

Teams video conferencing lag is not an unsolvable problem, the key lies in systematic troubleshooting and precise optimization. From terminals, local networks to enterprise export strategies, every link can become a bottleneck. Through the practical solutions provided in this article, both individual users and IT administrators can improve their Teams meeting experience in a targeted manner.

二、Shigeng Communication Global Office Network Products:

The global office network product of Shigeng Communication is a high-quality product developed by the company for Chinese and foreign enterprise customers to access the application data transmission internet of overseas enterprises by making full use of its own network coverage and network management advantages.

Features of Global Application Network Products for Multinational Enterprises:

1. Quickly access global Internet cloud platform resources

2. Stable and low latency global cloud based video conferencing

3. Convenient and fast use of Internet resource sharing cloud platform (OA/ERP/cloud storage and other applications

Product tariff:
